- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com/c/en_au
- Brand Name
- Cisco
- Product Line
- Catalyst
- Product Series
- 3650
- Product Type
- Ethernet Switch
Cisco announces the end-of-sale and end-of-life dates for the Cisco Catalyst 3650 Mini. The last day to order the affected product(s) is May 31, 2023. Customers with active service contracts will continue to receive support from the Cisco Technical Assistance Center (TAC) as shown in Table 1 of the EoL bulletin. Table 1 describes the end-of-life milestones, definitions, and dates for the affected product(s). Table 2 lists the product part numbers affected by this announcement. For customers with active and paid service and support contracts, support will be available under the terms and conditions of customers' service contract.
- Interfaces/Ports
- Total Number of Network Ports
- 24
- Uplink Port
- Yes
- Stack Port
- Yes
- Port/Expansion Slot Details
- 24 x Gigabit Ethernet PoE+
- 2 x 10 Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Optical Fiber
- Twisted Pair
- Ethernet Technology
- Gigabit Ethernet
- 10 Gigabit Ethernet
- I/O Expansions
- Total Number of Expansion Slots
- 2.0
- Expansion Slot Type
- SFP+
- Number of SFP+ Slots
- 2
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3z
- IEEE 802.1Q
- IEEE 802.1D
- IEEE 802.3ab
- IEEE 802.1p
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.3ad
- IEEE 802.1w
- IEEE 802.1s
- IEEE 802.1x
- IEEE 802.1ab
- IEEE 802.3at
- Management & Protocols
- Manageable
- Yes
- Power Description
- PoE Budget
- 390 W
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- AC
- Redundant Power Supply Supported
- Yes
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Compatible Rack Unit
- 1U
- Form Factor
- Desktop
- Rack-mountable
- Height
- 43.2 mm
- Width
- 444.5 mm
- Depth
- 447 mm
- Weight (Approximate)
- 7.26 kg
- Miscellaneous
- Application/Usage
- Business
- Network
