- General Information
- Manufacturer
- Ubiquiti Inc.
- Manufacturer Website Address
- http://www.ui.com
- Brand Name
- Ubiquiti
- Product Type
- Ethernet Switch
A 24-port, Layer 2 PoE switch designed for ISP networks.
Features:
- (24) GbE RJ45 ports, including (16) with 27V passive PoE output
- (4) 10G SFP+ ports
- 220W (27V) total PoE availability, 15W/port (2-pair) / 30W/port (4-pair)
- 1.3" LCM color touchscreen
- Easy Bluetooth setup with the UISP Mobile app
- Interfaces/Ports
- Total Number of Network Ports
- 24
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 24 x Gigabit Ethernet Network
- 4 x 10 Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- 10 Gigabit Ethernet
- I/O Expansions
- Total Number of Expansion Slots
- 4.0
- Expansion Slot Type
- SFP+
- Number of SFP+ Slots
- 4
- Network & Communication
- Layer Supported
- 2
- Management & Protocols
- Manageable
- Yes
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Power Source
- Power Supply
- Power Consumption
- 30 W
- Physical Characteristics
- Product Material
- Steel
- Polycarbonate
- ABS
- Form Factor
- Enclosure
- Height
- 43.7 mm
- Width
- 442.4 mm
- Depth
- 267.5 mm
- Weight (Approximate)
- 4 kg
- Miscellaneous
- Application/Usage
- Network
